www.ti.com Device Emulation Registers
Figure 5-2. Part ID Register
15 8 7 0
PARTTYPE PARTNO
R R
LEGEND: R/W = Read/Write; R = Read only; - n = value after reset
Table 5-17. PARTID Register Field Descriptions
Bit Field Value
(1)
Description
15:8 PARTTYPE These 8 bits specify the type of device such as flash-based.
0x 00 Flash-based device
All other values are reserved.
7:0 PARTNO These 8 bits specify the feature set of the device as follows:
0x00EF F28335
0x00EE F28334
0x00ED F28332
0x00E8 F28235
0x00E7 F28234
0x00E6 F28232
(1)
The reset value depends on the device as indicated in the register description.
Figure 5-3. CLASSID Register
15 8 7 0
PARTTYPE CLASSNO
R R
LEGEND: R/W = Read/Write; R = Read only; - n = value after reset
Table 5-18. CLASSID Register Description
Bits Field Value Description
15-8 PARTTYPE These 8 bits specify the type of device such as flash-based.
0x00 Flash-based device
All other values are reserved.
7-0 CLASSNO These 16 bits specify the class for the particular part.
0x00EF F28335, F28334, TMS320F2833x Floating Point Class device
F28332
0x00E8 F28235, F28234, TMS320F2823x Fixed Point Class device
F28232
Figure 5-4. REVID Register
15 0
REVID
R
LEGEND: R/W = Read/Write; R = Read only; - n = value after reset
SPRUFB0C – September 2007 – Revised May 2009 Peripheral Frames 117
Submit Documentation Feedback
