Flash and OTP Registers
www.ti.com
Figure 1-4. Flash Options Register (FOPT)
15 1 0
Reserved ENPIPE
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; - n = value after reset
Table 1-2. Flash Options Register (FOPT) Field Descriptions
Bit Field Value Description
(1) (2) (3)
15-1 Reserved
0 ENPIPE Enable Flash Pipeline Mode Bit. Flash pipeline mode is active when this bit is set. The pipeline
mode improves performance of instruction fetches by pre-fetching instructions. See Section 1.2.2
for more information.
When pipeline mode is enabled, the flash wait states (paged and random) must be greater than
zero.
On flash devices, ENPIPE affects fetches from flash and OTP.
0 Flash Pipeline mode is not active. (default)
1 Flash Pipeline mode is active.
(1)
This register is EALLOW protected. See Section 5.2 for more information.
(2)
This register is protected by the Code Security Module (CSM). See Chapter 2 for more information.
(3)
When writing to this register, follow the procedure described in Section 1.2.4 .
Figure 1-5. Flash Power Register (FPWR)
15 2 1 0
Reserved PWR
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; - n = value after reset
Table 1-3. Flash Power Register (FPWR) Field Descriptions
Bit Field Value Description
(1) (2)
15-2 Reserved
1-0 PWR Flash Power Mode Bits. Writing to these bits changes the current power mode of the flash bank
and pump. See section Section 1.2 for more information on changing the flash bank power mode.
00 Pump and bank sleep (lowest power)
01 Pump and bank standby
10 Reserved (no effect)
11 Pump and bank active (highest power)
(1)
This register is EALLOW protected. See Section 5.2 for more information.
(2)
This register is protected by the Code Security Module (CSM). See Chapter 2 for more information.
Flash and OTP Memory Blocks22 SPRUFB0C – September 2007 – Revised May 2009
Submit Documentation Feedback
