www.ti.com Interrupt Sources
Table 6-4. PIE MUXed Peripheral Interrupt Vector Table
INTx.8 INTx.7 INTx.6 INTx.5 INTx.4 INTx.3 INTx.2 INTx.1
INT1.y WAKEINT TINT0 ADCINT XINT2 XINT1 Reserved SEQ2INT SEQ1INT
(LPM/WD) (TIMER 0) (ADC) Ext. int. 2 Ext. int. 1 - (ADC) (ADC)
0xD4E 0xD4C 0xD4A 0xD48 0xD46 0xD44 0xD42 0xD40
INT2.y Reserved Reserved EPWM6_ TZINT EPWM5_TZINT EPWM4_TZINT EPWM3_TZINT EPWM2_TZINT EPWM1_TZINT
- - (ePWM6) (ePWM5) (ePWM4) (ePWM3) (ePWM2) (ePWM1)
0xD5E 0xD5C 0xD5A 0xD58 0xD56 0xD54 0xD52 0xD50
INT3.y Reserved Reserved EPWM6_ INT EPWM5_INT EPWM4_INT EPWM3_INT EPWM2_INT EPWM1_INT
- - (ePWM6) (ePWM5) (ePWM4) (ePWM3) (ePWM2) (ePWM1)
0xD6E 0xD6C 0xD6A 0xD68 0xD66 0xD64 0xD62 0xD60
INT4.y Reserved Reserved ECAP6_INT ECAP5_INT ECAP4_INT ECAP3_INT ECAP2_INT ECAP1_INT
- - (eCAP6) (eCAP5) (eCAP4) (eCAP3) (eCAP2) (eCAP1)
0xD7E 0xD7C 0xD7A 0xD78 0xD76 0xD74 0xD72 0xD70
INT5.y Reserved Reserved Reserved Reserved Reserved Reserved EQEP2_INT EQEP1_INT
- - - - - - (eQEP2) (eQEP1)
0xD8E 0xD8C 0xD8A 0xD88 0xD86 0xD84 0xD82 0xD80
INT6.y Reserved Reserved MXINTA MRINTA MXINTB MRINTB SPITXINTA SPIRXINTA
(McBSP-A) (McBSP-A) (McBSP-B) (McBSP-B) (SPI-A) (SPI-A)
0xD9E 0xD9C 0xD9A 0xD98 0xD96 0xD94 0xD92 0xD90
INT7.y Reserved Reserved DINTCH6 DINTCH5 DINTCH4 DINTCH3 DINTCH2 DINTCH1
(DMA6) (DMA5) (DMA4) (DMA3) (DMA2) (DMA1)
0xDAE 0xDAC 0xDAA 0xDA8 0xDA6 0xDA4 0xDA2 0xDA0
INT8.y Reserved Reserved SCITXINTC SCIRXINTC Reserved Reserved I2CINT2A I2CINT1A
- - (SCI-C) (SCI-C) - - (I2C-A) (I2C-A)
0xDBE 0xDBC 0xDBA 0xDB8 0xDB6 0xDB4 0xDB2 0xDB0
INT9.y ECAN1INTB ECAN0INTB ECAN1INTA ECAN0INTA SCITXINTB SCIRXINTB SCITXINTA SCIRXINTA
(CAN-B) (CAN-B) (CAN-A) (CAN-A) (SCI-B) (SCI-B) (SCI-A) (SCI-A)
0xDCE 0xDCC 0xDCA 0xDC8 0xDC6 0xDC4 0xDC2 0xDC0
INT10.y Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
- - - - - - - -
0xDDE 0xDDC 0xDDA 0xDD8 0xDD6 0xDD4 0xDD2 0xDD0
INT11.y Reserved Reserved Reserved Reserved Reserved Reserved Reserved
- - - - - - - -
INT12.y LUF LVF Reserved XINT7 XINT6 XINT5 XINT4 XINT3
(FPU) (FPU) - Ext. Int. 7 Ext. Int. 6 Ext. Int. 5 Ext. Int. 4 Ext. Int. 3
SPRUFB0C – September 2007 – Revised May 2009 Peripheral Interrupt Expansion (PIE) 133
