Interrupt Sources
www.ti.com
Table 6-4. PIE MUXed Peripheral Interrupt Vector Table (continued)
INTx.8 INTx.7 INTx.6 INTx.5 INTx.4 INTx.3 INTx.2 INTx.1
0xDFE 0xDFC 0xDFA 0xDF8 0xDF6 0xDF4 0xDF2 0xDF0
Table 6-5. PIE Vector Table
PIE Group
Name VECTOR ID
(1)
Address
(2)
Size (x16) Description
(3)
CPU Priority Priority
Reset 0 0x0000 0D00 2 Reset is always fetched from location 0x003F FFC0 in 1 -
Boot ROM. (highest)
INT1 1 0x0000 0D02 2 Not used. See PIE Group 1 5 -
INT2 2 0x0000 0D04 2 Not used. See PIE Group 2 6 -
INT3 3 0x0000 0D06 2 Not used. See PIE Group 3 7 -
INT4 4 0x0000 0D08 2 Not used. See PIE Group 4 8 -
INT5 5 0x0000 0D0A 2 Not used. See PIE Group 5 9 -
INT6 6 0x0000 0D0C 2 Not used. See PIE Group 6 10 -
INT7 7 0x0000 0D0E 2 Not used. See PIE Group 7 11 -
INT8 8 0x0000 0D10 2 Not used. See PIE Group 8 12 -
INT9 9 0x0000 0D12 2 Not used. See PIE Group 9 13 -
INT10 10 0x0000 0D14 2 Not used. See PIE Group 10 14 -
INT11 11 0x0000 0D16 2 Not used. See PIE Group 11 15 -
INT12 12 0x0000 0D18 2 Not used. See PIE Group 12 16 -
INT13 13 0x0000 0D1A 2 External Interrupt 13 (XINT13) or CPU-Timer1 17 -
INT14 14 0x0000 0D1C 2 CPU-Timer2 18 -
(for TI/RTOS use)
DATALOG 15 0x0000 0D1E 2 CPU Data Logging Interrupt 19 (lowest) -
RTOSINT 16 0x0000 0D20 2 CPU Real-Time OS Interrupt 4 -
EMUINT 17 0x0000 0D22 2 CPU Emulation Interrupt 2 -
NMI 18 0x0000 0D24 2 External Non-Maskable Interrupt 3 -
ILLEGAL 19 0x0000 0D26 2 Illegal Operation - -
USER1 20 0x0000 0D28 2 User-Defined Trap - -
USER2 21 0x0000 0D2A 2 User Defined Trap - -
USER3 22 0x0000 0D2C 2 User Defined Trap - -
USER4 23 0x0000 0D2E 2 User Defined Trap - -
USER5 24 0x0000 0D30 2 User Defined Trap - -
(1)
The VECTOR ID is used by DSP/BIOS.
(2)
Reset is always fetched from location 0x003F FFC0 in Boot ROM.
(3)
All the locations within the PIE vector table are EALLOW protected.
134 Peripheral Interrupt Expansion (PIE) SPRUFB0C – September 2007 – Revised May 2009
Submit Documentation Feedback
