120
FUNCTION SETTING USING SETTINGS SCREEN
Cyl Sign
+ Astigma sign is displayed with "+."
- 153- Astigma sign is displayed with "-."
MIX Astigma sign is displayed with "MIX."
Topo-map
Smoothing
ON Performs top-map smoothing.
OFF 153
OFF Top-map smoothing is not done.
Progress Map
graph scale
0.1 Graph scale of progress map is set to 0.1.
1.0 153
0.2 Graph scale of progress map is set to 0.2.
0.5 Graph scale of progress map is set to 0.5.
1.0 Graph scale of progress map is set to 1.0.
2.0 Graph scale of progress map is set to 2.0.
Map of analysis
screen layout
button 1
Multi map
Layout 1 of measurement result screen is set to
multi maps.
Multi Maps 153
Ocular aberration map
Layout 1 of measurement result screen is set to
ocular aberration maps (Ocular Maps).
Zernike vector map
Layout 1 of measurement result screen is set to
zernike vector maps (Zernike Maps).
Progress map
Layout 1 of measurement result screen is set to
progress maps (Summary Maps).
Component map
Layout 1 of measurement result screen is set to
component maps (Component Maps).
IOL selection map
Layout 1 of measurement result screen is set to
IOL selection maps (IOL Selection Maps).
PSF/MTF map
Layout 1 of measurement result screen is set to
PSF/MTF maps (PSF/MTF Maps).
Corneal R/L map
Layout 1 of measurement result screen is set to
Corneal R/L maps.
Ocular R/L map
Layout 1 of measurement result screen is set to
Ocular R/L maps.
Map of analysis
screen layout
button 2
Same as above. Same as above except layout 1 layout 2.
Ocular
aberration
map
154
Map of analysis
screen layout
button 3
Same as above. Same as above except layout 2 layout 3.
Corneal
aberration
map
154
Map of analysis
screen layout
button 4
Same as above. Same as above except layout 3 layout 4.
Compo-
nent map
154
Corneal irregular
astig. 1
(Threshold 1 <
Threshold2)
Set by ten-key display
First threshold value of corneal irregular astigmatism
is set.
0.3 155
Corneal irregular
astig. 2
(Threshold 1 <
Threshold2)
Set by ten-key display
Second threshold value of corneal irregular astigma-
tism is set.
0.6 155
K Readings Set by ten-key display K threshold value is set. 0.5 156
Corneal SA Set by ten-key display
Threshold value of corneal spherical aberration is
set.
0.1 156
Corneal astig. Set by ten-key display Threshold value of corneal astigmatism is set. 1.5 156
RMS threshold 1
(4mm)
(Threshold 1 <
Threshold2)
Set by ten-key display The first RMS threshold (4mm) is set. 0.30 157
RMS threshold 2
(4mm)
(Threshold 1 <
Threshold2)
Set by ten-key display The second RMS threshold (4mm) is set. 0.60 157
Set item display Setting Change button Set contents Initial value Page
To Next Page
