6.10 ADMIN Commands 95
7. Programming 96
7.1 Denions 96
7.2 G-code Programming Language 99
7.2.1 Overview 99
7.2.2 Block 99
7.2.3 Real Value 99
7.2.4 Number 99
7.2.5 Formang G-code Blocks 100
7.2.6 Oponal Program Stop Control – (M01 BREAK) 103
7.2.7 Addional G-code Formang Notes 104
7.2.7.1 Repeated Items 104
7.2.7.2 Order of Execuon 104
7.2.7.3 Error Handling 106
7.2.7.4 Modality and Modal Commands 106
7.2.7.5 Modal Groups 106
7.2.7.6 Default Modes 107
7.3 G-codes 107
7.3.1 Rapid Linear Moon – G00 109
7.3.2 Linear Moon at Feed Rate – G01 110
7.3.3 Arc at Feed Rate – G02, G03 111
7.3.3.1 Radius Format Arc 111
7.3.3.2 Center Format Arc 112
7.3.4 Dwell – G04 115
7.3.5 Set Osets – G10 115
7.3.5.1 Set Tool Table – G10 L1 115
7.3.5.2 Set Coordinate System – G10 L2 115
