Chapter 9
167
UM10350_PCNC770_Manual_0916A
Maintenance
Figure 9.5
Sleeve
Cover Plate
Adjustment Nut
Lock Nut
Spacer
Bearing Outer Race
Figure 9.4
Motor
Bearing Adjustment Nuts
Bearing Pair
Ball Screw
