Troubleshooting
Is there any electrical
power in the machine,
coolant pump, and/or
controller?
Start
Refer to Power Distribuon Subsystem.
End
Can you turn on
control power
(Machine LED is On)?
Refer to Control Power Subsystem.
Refer to Controller Communicaon
Subsystem.
Can you turn on
controller LED?
Refer to Axis Drive Subsystem.
Are the X, Y, Z and A
axes funconing
properly?
Refer to Spindle Drive Subsystem.
Is the spindle drive
funconing properly?
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
Figure 10.3
