Chapter 10
211
UM10350_PCNC770_Manual_0916A
Troubleshooting
Spindle Drive Subsystem Checklist
Table 5.1 (...continued)
Spindle will not turn on in manual or auto
Possible Cause Probability
Action to Identify Cause of Problem
Discussion
VFD is not
programmed or
is programmed
incorrectly
Low
Push the M button on the front panel
of the VFD momentarily. The display
will change to 01___0.0 with the 01
blinking. Momentarily push the up
arrow key to the right of the M key,
the 01 changes to 02. Take note of the
number to the right of the 02. Your
VFD should read 148.X, where X
designates the VFD program version. If
it does not display this value then your
VFD requires reprogramming. To exit
this mode, push and hold the M button
until the display reverts.
Reprogramming a VFD is
a simple operation, but
requires a programming stick
from Tormach.
(connued on next page...)
