tornos DECO 7/10 - Example 1: Standard Programming

OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 15.7.2 /8
15.7.1 Example 1: Standard Programming
− M892 (NSK spindle ON)
− M103 S50.
− G1 X3 = −2 G100 M150.
− G1 Z3 = 1 G100.
−M1
− G1 Z3 = −4.5 F0.4 (Whirling M2 x 0.4 mm)
− M105.
− G1 X3 = −1.5 G100 M151.
− G1 Z3 = 20 G100.
− M893 (NSK spindle OFF)
15.7.2 Example 2: Programming C-axis
− M892 (NSK spindle ON)
− M103 S0 (random)
− G1 X3 = −2 G100 M150
− G1 Z3 = 1 G100
−M1
− M198 (S4 in C-axis).
− G1 C1 = 4950 Z3 = −4.5 F18000 G94 (Whirling)
− G1 X3 = −1.5 G100
− G1 Z3 = 20 G100 M151
− M893 (NSK spindle OFF)
− M199 (S1 C-axis)
