OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e

300236 en − 02/07 Chap. 20.2 /6

20.2 (305128) LONG PART CATCHER

COMPONENTS

Item Designation

070 Chute

300 Thrustor

305128

LONG-PART CATCHER EQUIPMENT

To be selected as required:

Désignation

305116 Long-Part Ejector; see Para. 19.1

305130 Long-Part Evacuation Pneumatics; see Para. 19.3

305121 + 305129 Bar Retention Claws; see Chapter 18
