OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 21.2 /5
21.2 CHIPR REUPERATOR PROGRAMMING
The declaration of the option, the programming of engagement and
disengagement must be effected according to the following directions.
The option chip conveyor is used for the control of the cleaning pump
Unlock access to parameters:
− Select mode “MDI” on operator panel.
− Press key “OFFSET SETTING”
− Select page “SETTING/HANDY”
(Select channel 2 if the page does not get selected).
− Move with the arrows.
− Set PARAMETER WRITE = 1
Declaration of option chip conveyor K1.2 = 1.
− Select mode “MDI” on operator panel.
−Press key “SYSTEM” on CNC
( PMC )
− Press softkey “PMC”.
(PMCPRM)
− Press softkey “PMCPRM”.
(KEEPRL)
− Press softkey “KEEPRL”.
PMC PRM (KEEP RELAY) MONIT (RUN / STOP)
ADDRESS DATA ADDRESS DATA
K00 K10 000000000
K01 K11 000000000
K02 K12
K03
K08 K19
(TIMER) (COUNTER) (KEEPRL) (DATA) (SETTING)
