tornos DECO 7/10 - 305102) Long Powered Spindle 3610

OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 5.4 /7
5.4 (305102) LONG POWERED SPINDLE 3610
COMPONENTS
Item Designation
050 Feed fork
80 Eccentric sleeve
230 Lock
400 Lateral setting screw
410 Nipple
1010 Leak-oil drain hole
. Caution !
Direct Leak-Oil Drain Hole 1010 downwards.
The spindle bearings can jam if the joint does not work correctly.
305102f
