OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 14.1 /1
14. (305112) INTERNAL THREAD WHIRLING ON BACKWORK GANG (T41−T44) 4400
14.1 GENERAL NOTES AND TECHNICAL DATA
TECHNICAL DATA
1.
Operating Principle
A single-insert cutter rotates and attains a speed of 30000 rpm. The part
rotates at 50 rpm. Interpolation of the axis rpm and feed rate ensures execu-
tion of a thread in a single pass.
Remarque:
For motor operation and maintenance, see Supplier Documentation
of NSK delivered with each attachment.
Feature
Description /
Notes
Data
2. Cutter Drive Spindle motor: Pneumatic
Make: NSK
Type: NR 301
Speed: 30000 rpm
Torque max.: 0,01 Nm
3. Cutter
Type:
Thread milling cut-
ter, monoblock
Material: Carbide
Form: ISO 60
Dimensions (example): M2, 3 mm working length
M1.6, 3.5 mm working length
M1.4, 2.3 mm working length
− Collet: CHG (NSK)
− Insert: 1 RH
− Supplier: Friedrich GLOOR AG
Cutter: M1.6, RH insert
