tornos DECO 7/10 - Programming the Mechanical Locking System

OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 18.1 /7
18.1 PROGRAMMING THE MECHANICAL LOCKING SYS-
TEM.
The locking procedure is a 3−step procedure:
1) Position the spindle at the desired degree by using the function Mx19 Q..
2) Deactivate the servo−mechanism of the motor S1 or S4 by using the func-
tion M800 P1=−..., before engaging the lock.
3) Engage the compressed air lock by using the functions M831 or M841.
Note:
The spindle has to be de−servoed to prevent stress forces on the motor
if the toothed disk has not been correctly adjusted. If these stress
forces are too high, a NC alarm may be triggered.
TYPICAL ISO CODE FOR LOCKING/UNLOCKING :
Line Spindle S1 Counter−spindle S4
1 M103 S0 M403 S0
2 G4 X… G4 X…
3 M119 Q0 M419 Q0
4 G4 X… G4 X…
5 M800 P1=−1700 M800 P1=−1703
6 M831 M841
7 G4 X0.5 G4 X0.5
8 Machining Machining
9 M832 M842
10 G4 X0.5 G4 X0.5
Line 5: Spindle de−servoing by using the function M800.
P1=−1700 for spindle S1
P1=−1703 for spindle S4.
Line 6/9: M831/M832 = engage/disengage the lock S1
M841/M842 = engage/disengage the lock S4
Line 7/10: Mandatory timeout of 0.5 sec. to allow the lock to be correctly
engaged.
Line 2/4: Timeouts to be programmed according to the kind of machine.
