OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 14.6 /7
14.6 OPTIMUM CUTTING DATA
TECHNICAL DATA
Feature Description Data
Cutter speed: 30000 rpm
Spindle speed: 50 rpm
Rotation direction: CCW
Milling method: down milling
Milling direction: from outside inwards
Insert: RH
Lubricant pressure: ≥ 3bars
Lubrication method: injection nozzle
1305
M 1,6
The drawing demonstrates, while retaining true proportions, the space
between the cutter and the bore diameter during cutting. To evacuate the
chips, the oil jet must be precisely directed.
>>>
