OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 5.1 /1
5. SPINDLES
5.1 (305054) FIXED SPINDLE FOR ESX 12 COLLETS
3100
COMPONENTS
Item Designation
030 Feed fork
040 Eccentric sleeve
110 Nipple
140 Lateral setting screw
ESX 12 FIXED SPINDLE DATA
Feature Description / Notes Data
Mounting stations : T31, T32, T33
Capacity : ESX 12 7 mm
ET 12 M4
Selection stroke : 30 mm
Longitudinal setting : (Z3) 80 à 120 mm
Lateral setting : (Y3) +/− 0,5 mm
Off-center radius : 3 mm
CHANGING TOOLHOLDER
To start with : Put the machine in SETTING mode.
What to do ? Notes
Dismounting
Unscrew both Fastening screws 130.
Dismount the toolholder.
Mounting
Fit the toolholder in place ...
Fit + tighten both Fastening screws
130
... locating it with the two pins.
LATERAL SETTING OF TOOLHOLDER
To start with : Put the machine in SETTING mode.
What to do ? Notes
Setting
Loosen both screws 140.
Unscrew one of them and screw in
the other one and proceed to set ...
Tighten both screws 140 ...
... by pivoting Eccentric sleeve
040.
... once set as required.
GREASING BEVEL GEARS
Maintenance Interval: Grease the fixed spindle semi-annually or at least
every 1000 hours’ operation.
To start with: Fill up the grease pump. see Instr. 300231, Chapter 2.
What to do ? Notes
Greasing
Grease over Nipple 110 ...
... until the grease comes out of
the eccentric sleeve.
