OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 4. /2
SLOTTING ATTACHMENT DATA
Feature Description / Notes Data
Mounting positions : T21, T22, T23, T24
Capacity : ESX 12 7 mm
ET 12 M4
Circular cutter maxi 50 mm
Height setting : 15 mm maxi
with 5 and 10 mm
spacers
Speed, max.: maxi 12000 rpm
SLOTTING ATTACHMENT OPERATION
The attachment is equipped with a spindle :
Spindle support : preloaded ball bearings in the front deep groove
ball bearing in the back
Spindle bearing greasing : The bearings are pregreased for life.
Spindle drive : over a notched pulley,screwed and secured at
the rear end of the spindle
Spindle immobilization : over Hole 1010 to unscrew cutter holder nut
TOOLHOLDER CHANGE
Identical with Gang Toolholder Change 305018: see Instructions 300231,
Page 8/19.
See also Gang Tooling Drive Belt Layout 305018: ditto, Page 8/17
