11. (305092) MILLING / SLOTTING ATTACHMENT IN T33 3700

TECHNICAL DATA

This is a special attachment for the connector industry.

Material machined : brass

Eléments Description Caractéristiques

Circular cutter ∅, max.: maxi. 35 mm

Selection stroke : 30 mm

Speed : 12000 rpm

Torque : 0,05 Nm

1001

Piping bracket

NSK spindle

320150080

170

020

300

160

030

305092

010
