OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 3. /1
3. (305058) RADIAL POLYGONING ATTACHMENT 1700
COMPONENTS
Item Designation
030 Sleeve
070 Drive shaft
180 Cutter fastening screw
450 Fastening screw
POLYGONING ATTACHMENT DATA
Feature Description Data
Mounting position for DECO 2000 in T24 only
Cutter ∅ : ∅ 40 mm
Gearing up: 1 : 1,333
Cutter speed, max.: maxi 12000 rpm
POLYGONING ATTACHMENT OPERATION
Cutter holding spindle support: preloaded ball bearings
Spindle bearing greasing: The bearings are pregreased for life.
Spindle drive: over a pair of bevel gears and a timing belt without backlash
