13. (305107) DIFFERENTIAL-THREADING/TAPPING SPINDLE FOR S1/S3 3620
(OPTION 3620)
13.1 GENERAL
For basic instructions see Para. 4.3.
13.2 TECHNICAL DESCRIPTION
Fig. 1201 to1204
− Mounting positions : T31 − T32 − T33.
− Guard adaptation : required acc. to Fig. 1203 on machines with
an earlier type of Guard 3, Fig. 1202
− Spindle travel, max. : 50 mm
− Spring 2, Fig. 1202 : to be selected acc. to thread dimensions
(from three springs varying in force and
delivered with each unit)
13.3 MANUAL GREASING
Put in oil through Nipple 1, Fig. 1202.
Use oils indicated in the table below.
ENERGOL
HLP−D10
TELLUS
OIL C 10
VELOCITE
OIL No. 6
DTE 21
Mobil
M
OTOREX
Standard
COREX
HLP 220
ISO−L−FD 10
BP
