OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 8.2 /3
8.2 (305069) LASER SENSOR
APPLICATION
The sensor of modular design is used in :
Désignation
305069 Laser sensor
DECO 2000 7 mm / DECO 2000 10 mm
COMPONENTS
Item Components
010 M6 rods
020 M5 rods
030 Fixing stud
040 8 mm ∅ rod
050 Cover
160 Electro-valves YV 10 − 12YV
200 Sensor cleaning air flow limiter
260 Clamp
290 Laser sensor
Δ Danger ! Do not direct the laser beam against your eyes. Avoid looking
fixedly at the laser beam.
. Caution !
− The laser beam and tool rotation frequencies interfere with each other.
This results for certain speeds in a stroboscopic effect which affects
the monitoring.
− The laser beam reflection on the swarf or other surfaces in the
measurement area may be misinterpreted as the presence of a drill.
− Direct the laser beam perpendicularly to the monitored surface.
− Before monitoring, clean the sensor with compressed air for 1 to 1.5 s.
− Provide the sensor with Aluminium Cover 050 for good operation.
DESCRIPTION
Laser reflex sensor with background elimination
Tool detection by a very fine beam.
Good operation guaranteed if the laser beam hole and the monitored tool are
cleaned with compressed air.
