18. (305125) LOCKING SYSTEM FOR ORIENTED
PICKOFF SPINDLE 4040
PICKOFF-SPINDLE LOCKING SYSTEM APPLICATION
Stopping system:
Désignation
305063 for Spindle
. Caution !
For correct operation of the system, follow strictly the instructions given
in this chapter.
FUNCTION
Improving positioning precision and rigidity after oriented pickoff spindle stop
Mounting: optionally on pickoff headstock
PICKOFF-SPINDLE LOCKING SYSTEM DATA
Feature Description Data
Standard notched disk: 24 x 15°-divisions
Positioning precision: 0.1°
Locking torque: 17 Nm
305125a
208585
216532
217294
216536
305125
