tornos DECO 7/10 - 20 Long Part Evacuation 4900; 305116) Long Part Ejector

OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 20.1 /1
20. LONG PART EVACUATION 4900
20.1 (305116) LONG PART EJECTOR
LONG PART EJECTOR APPLICATION
On 7&10mm-capacity DECO 2000, Versions 0003 and 0004 in Positions T41
and T42.
TECHNICAL DATA
Feature Description Data
Thrustor stroke: 312 mm
Ejection rod: 561637 ∅ 4 / ∅ 2
Ejection rod: 561701 ∅ 3
OPERATION
The thrustor ejection rod allows to push the parts through the opposite spindle
positioned in T41.
The guiding plate of the ejection rod allows to adapt rods of ∅ 4 and ∅ 3 mm.
The rod ∅ 4 / ∅ 2 is hollow and allows to adapt endpieces.
>>>
