OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e

300236 en − 02/07 Chap. 16. /1

16. (305115) EXTERNAL THREAD WHIRLING IN T33 POSITION 3650

305115a

. Caution !

Crash hazard with external thread whirler in T33.

Always begin referencing axes with Z3 and X3 and only then coninued

with the other axes.

>>>
