OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e

300236 en − 02/07 Chap. 19. /1

19. (305121) BAR RETENTION CLAWS 2900

FUNCTION 2900

COMPONENTS

Item Designation

010 V-claw holder

020 Outside V-claw

030 Inside V-claw

040 Locking screw

200 Compression spring 200973 (fitted ex works)

210 Compression spring 212766

305121
