tornos DECO 7/10 - 96 ) Cross Drilling; Milling Attachment

170 pages

Save Page as PDF

To Next Page

To Previous Page

OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e

300236 en − 02/07 Chap. 12. /1

12. 305096) CROSS DRILLING / MILLING ATTACHMENT

TECHNICAL DATA

This is a special attachment for the connector industry.

Material machined: brass

Eléments Description Caractéristiques

Circular cutter ∅, max.: maxi. 30 mm

Speed: 30000 rpm

Torque: 0,01 Nm

110

305096f1
