OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e

300236 en − 02/07 Chap. 12.3 /3

1102

30000 t/min.

NSK ASTRO SYSTEM SPINDLE

Motor AM−300 216959

Air Unit K−234 216966

Speed Reducer ARG−01 216963

Spindle NR−302 242422

Arbor KCH−03

Chuck CHK−K−265

12.3 PNEUMATICS

1103

Additional Baseplate 305072

Magic

Guidebush

Laser

NSK spindle

Injector

NSK spindle
