OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e

300236 en − 02/07 Chap. 12.3 /4

1104

1106

Table of Contents

Default Chapter3
- Table of Contents3
1 Generalities11
- Differentiation of Degrees of Risk12
- Important Safety Indications12
305009 ) Cross Drilling Attachment 160013
- 305049) Spacers 161014
305058 ) Radial Polygoning Attachment 170015
- Polygon Milling Tooling18
305066 ) Slotting Attachment for 30−50Mm−Od Cutters 180019
5 Spindles21
- 305054) Fixed Spindle for Esx 12 Collets 310021
- 305143) Fixed Spindle for Wj8 Collets (Watch Industry) 311523
- 305006) Live Spindle for Esx 12 Collets 360025
- 305102) Long Powered Spindle 361027
6 Drilling / Slotting Attachment31
- 305056) Slotting Attachment for Backworking 470033
242447 ) Attachment for Cutting Pinions by Generation35
- Inclination of the Equipment36
- Presetting37
- Sample Programming38
8 Peripherals & Other Options39
- Tool Breakage39
- Frontwork Tool Breakage Sensor 512039
- Backwork Tool Breakage Sensor40
- 305069) Laser Sensor41
- Mist & Smoke Control44
- Fb 703 Fire Prevention Unit 548347
- Description47
- Application47
- Instructions and Documents47
305086 ) Oil Injector for Collet Rinsing 406049
10 Customer-Interface Options53
- General53
- Option Socket Inputs53
- Option Socket Outputs53
- Programming Optional Socket55
- Configurating Optional Socket 155
- Enable Input Check-Function Inside Program Loop56
- Enable / Disable Outputs on Optional Socket 156
- Programming Optional Socket57
- Configurating Optional Socket 257
- Enable / Disable Outputs on Optional Socket 258
- Kienzle Productivity-Monitor Control (an Example)59
- Wiring Diagram for Optional Socket 159
- Enable Outputs Inside Program Loop59
- Sensor Control Operation (an Example)60
- Wiring Diagram for Optional Socket60
- Configurating Optional Socket 2 Outside Program Loop60
- Enable Check by Input 1 Inside Program Loop60
- Drill Sensor Control (an Example)61
- Oil Level Check (an Example)62
- Single-Acting Piston Control Monitored by Two Sensors (an Example)63
- Enable Sensor Check Inside Program Loop64
- Piston Check Timing Diagram64
- Double-Acting Piston Control Monitored by Two Sensors (an Example)65
- Configurating Optional Socket 1 Outside Program Loop65
- Configurating Optional Socket 2 Outside Program Loop65
- Enable Sensor Check Inside Program Loop65
- Piston Check Timing Diagram67
- Optional Socket Diagram with Do Allocation68
- Optional Socket Configuration Flags69
- Enable / Disable Flags for Optional Socket Outputs69
305092 ) Milling / Slotting Attachment in T33 370071
- Technical Description72
- Manual Greasing72
- Nsk Spindle74
- Pneumatics74
- Operation79
96 ) Cross Drilling / Milling Attachment81
- Technical Description82
- Pneumatics83
- Nsk Spindle85
- Nsk Spindle Operation87
13 (305107) Differential-Threading/Tapping Spindle for S1/S3 3620 189
- General89
- Technical Description89
- Manual Greasing89
- Tests for Differential Threading on92
- Calculating Threading Ratio92
305112 ) Internal Thread Whirling on Backwork Gang (T41−T44) 440093
- General Notes and Technical Data93
- Centering Whirling Toolholder94
- 305113) Pneumatic Coolant System for Internal Thread Whirling on Frontwork & Backwork Gangs95
- Nsk Spindle98
- Pneumatics98
- Optimum Cutting Data99
- Programming Sample100
- Explanations to Example101
- Formula for One Variant101
305112 ) Internal Thread Whirling on Frontwork Gang (T31−T33) 3800103
- Centering Whirling Attachment104
- 305113) Pneumatic Coolant System for Internal Thread Whirling on Frontwork & Backwork Gangs105
- Nsk Spindle108
- Pneumatics108
- Manual Lubrication108
- Optimum Cutting Data109
- Whirling Programming Samples109
- Example 1: Standard Programming110
- Explanations to Examples 1 and 2111
- Formula for Two Variants111
305115 ) External Thread Whirling in T33 Position 3650113
- General Technical Data115
- Technical Data116
- Setting Whirling Attachment117
- Parallelism and Centering117
- Axial Alignment of Cutters119
- Whirling Programming Sample124
- Part Drawing124
- Programming124
- Technical Data and Calculations for External Whirling126
305124 ) Locking System for Oriented Main Spindle 0940129
- Programming the Mechanical Locking System134
- 306125) Locking Pneumatics for Oriented Main Spindle135
305125 ) Locking System for Oriented Pickoff Spindle 4040137
- Programming the Mechanical Locking System143
- 306125) Locking Pneumatics144
- 305185) Limiting Chucking Force Setting System Travel 4052145
305121 ) Bar Retention Claws 2900147
20 Long Part Evacuation 4900151
- 305116) Long Part Ejector151
- 305128) Long Part Catcher156
- 305130) Long Part Evacuation Pneumatics159
21 Chip Recuperator Outside Machine 5450161
- Chip Recuperator Description164
- Addresses165
- Chipr Reuperator Programming165
22 Index169
