6. DRILLING / SLOTTING ATTACHMENT
COMPONENTS
Item Designation
1010 Eccentric set screw
1020 Clamping screw
DRILLING / SLOTTING ATTACHMENT DATA
Number of modular slotting/milling fixtures: 1 to 3 in T42, T43, T44
Option 4500 (S5 drive): required
Number of drilling / milling fixtures: 1 in T42, T43, T44
If mounted, precludes the use of the next post.
Drive Belt Layout (305053): see Instructions 300231, Page
10/6
Stationary D25-Toolholder (305037): required, see Instructions 300231, Para.
10.2
Live D25-Spindle Roller (305046): required, see Instructions 300231, Para.
10.5
1020
1010
156556
