OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 6. /2
INSTALLATION OF DRILLING / SLOTTING ATTACHMENT
To start with: Put the machine in SETTING mode.
What to do ? Notes
Dismounting
Unscrew Eccentric Set Screw
1010.
Dismount the slotting unit.
Mounting
Mount the D25 toolholder.
Fit the slotting unit in place...
Position the slotting unit angularly
...
Screw in but do not tighten Eccen-
tric Set Screw 1010.
Center the D25 toolholder.
Align the attachment.
... through the front of the vertical
(support).
... on 0° or 90°
See LATERAL SETTING OF
D25-TOOLHOLDER, Instruction
300231, Page 10/4.
Alignment on 0° or 90°, see below.
ALIGNING DRILLING / SLOTTING ATTACHMENT
on Angular Position 0°
or 90°
To start with: Mount a dial gauge on the pickoff spindle carriage.
What to do ? Notes
Aligning
Loosen Clamping Screw 1020.
Turn Eccentric Set Screw 1010 ...
Tighten Clamping Screw 1020.
Shift the pickoff spindle carriage ...
... while holding down the attach-
ment.
... to establish a possible mis-
alignement of the attachment.
