OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 8.1.2 /2
8.1.2 Backwork Tool Breakage Sensor
Up to series 9
DESCRIPTION
Mounting on X4 carriage or in a fixed position facing backwork gang allows to
monitor the presence of backwork tools T41 to T44.
Note:
Mounting on X4 carriage precludes sensing in masked time.
Mounting in front of the backwork gang allows sensing in masked time
of a single Backwork Tool T41 to T44 only.
INSTALLATION
To start with : Sensor mounted, see Page 6/4.
What to do ? Notes
Mount and fasten the device on X4
carriage or above the pickoff
spindle nose.
SETTING SENSOR
To start with : Sensor tested, see Page 6/6.
What to do ? Notes
Clean the sensor with compressed
air.
Cleaning duration: approx. 1 to 1,5
sec. (according to trials)
Bring the tool to the sensing posi-
tion and adjust the sensor position
accordingly.
Laser beam to be seen on the tool.
Sensing distance 80 mm
(or 55 mm from the cover)
Check if the monitoring system
works.
