OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 8.1.1 /1
8. PERIPHERALS & OTHER OPTIONS
8.1 TOOL BREAKAGE
8.1.1 Frontwork Tool Breakage Sensor 5120
Up to series 9
DESCRIPTION
The sensor, mounted alongside the X1Y1 mainwork gang, allows :
a) checking the presence of Frontwork Tools T31 to T33;
b) checking if part is ejected from the pickoff spindle before the next part is
picked off;
c) checking if the cutoff tool is broken after pickoff spindle retracts with a part
picked off.
INSTALLATION
To start with : Sensor mounted, see Page 6/4.
What to do ? Notes
Mount and fasten the device
beside the X1 / Y1 gang tooling on
the vertical.
SETTING SENSOR
To start with : Sensor tested, see Page 6/6.
What to do ? Notes
Clean the sensor with compressed
air
Cleaning duration: approx. 1 to 1,5
sec. (according to trials)
Bring the tools to the sensing posi-
tion and adjust the sensor position
accordingly.
Laser beam to be seen on the tool.
Sensing distance 80 mm
(or 55 mm from the cover)
Check if the monitoring system
works.
