OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 18. /6
ORIENTED-PICKOFF-SPINDLE LOCKING SYSTEM OPERATION
Oriented pickoff spindle stop: by NC
Oriented-pickoff-spindle locking: by an air-actuated locking pin which locks in
the notched disk in the back of the pickoff spindle to fix the pickoff spindle posi-
tion.
Oriented-pickoff-spindle unlocking: by Spring 250 which retracts locking pin.
Standard notched disk: 24 x 15°-divisions
Backlash: reduced to minimum due to slant of disk notches and locking pin
Note:The electric pickoff-spindle control is off for unhindered locking /
unlocking action.
>>>
