FITTING LOCKING MECHANISM
What to do ? How ? What for ? Notes
Mount Locking Mechanism Sup-
port 050 on the headstock slide.
Insert Screws 230 without tighten-
ing them.
Connect the locking mechanism to
the pneumatic unit...
... (see Para. 17.2 LOCKING
PNEUMATICS below).
Make sure that Locking Pin 030
approximately faces a notch of the
disk.
Activate Locking Pin 030 over NC
to lock.
Tap on Cylinder 040 for snug lock-
ing.
Tighten Screws 230.
Deactivate Locking Pin 030 over
NC to unlock.
Fit in place Barguide-Tube Support
070.
Mount the guard.
ANGULAR SETTING OF SPINDLE LOCK
For profiled bars (square, hex), it may be necessary to orient the pickoff
spindle key in relation to the disk notches.
For the angularly positioned machining for profiled bars, proceed as fol-
lows:
What to do ? How ? What for ? Notes
Take down the guard.
Fit a profiled collet and bar in the
pickoff spindle and shift the bar up
to the tool line.
Close the collet.
Reduce the air pressure of the
conditioning unit by approx. 3 bars.
. Caution ! Position the pickoff
spindle in the approximately
required angle.
Activate Locking Pin 030 over NC
to lock.
Note:
Make sure that Locking Pin 030
approximately faces a notch of
the disk.
Loosen Screws 220.
Position the pickoff spindle in the
exactly required angle.
Tighten Screws 220...
...with 2 Nm torque as indicated on
the unit.
Deactivate Locking Pin 030 over
NC to unlock.
Reset the air pressure to its initial 6
bar.
Fit the guard in place.
