OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 18. /4
REPLACING REAR PICKOFF−SPINDLE−SPRING BUSHING
(Use Assembly Tooling 080, 090, 280 and 290 included in the option.)
What to do ? How ? What for ? Notes
Take down the headstock guard.
Remove Barguide-Tube Support
070.
Screw in Rod 080 in the pickoff
spindle.
Fit Roller Bearing 280, Screwed
Sleeve 090, Nut 290 on Rod 080
and screw Sleeve 090...
...until it leans against Bushing
020.
Tighten Nut 290 by approx. 0.5
mm to release the elastic SEEGER
ring.
Remove the elastic SEEGER ring.
Unscrew completely Nut 290.
Remove Bushing 020 without
bores.
Fit Bushing 020 with bores.
Fit again Roller Bearing 280,
Screwed Sleeve 090, Nut 290 on
Rod 080.
Retighten and fit in place the elas-
tic SEEGER ring.
Take down Assembly Tooling 080,
090, 280 and 290.
FITTING NOTCHED DISK
What to do ? How ? What for ? Notes
Align approximately the pickoff
spindle key located forward in the
headstock.
Fit Notched Disk 010 in the back of
the pickoff spindle.
(Align approximately the pickoff
spindle key and the next notch).
Tighten Screws 220...
...with 2 Nm torque as indicated on
the unit.
