OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 18. /3
COMPONENTS
Item Designation
Assembly Tooling
080 Rod
090 Screwed sleeve
280 Roller bearing
290 Nut
Locking System
010 Notched disk
020 Rear pickoff spindle-spring bushing, with bores
030 Locking pin
040 Cylinder
050 Locking-mechanism support
060 Cylinder cover
070 Cylinder cover fastening screw
210 Locking-mechanism fastening screw
220 Disk fastening screw
220 Vis de fixation du disque
1010 Bague SEEGER
DISMOUNTING
What to do ? How ? What for ? Notes
To dismount:
Take down the pickoff headstock
guard.
Remove Barguide-Tube Support
070.
Disconnect the air supply tube.
Unscrew Screw 210.
Remove the locking mechanism.
Unscrew Screws 220.
Withdraw Notched Disk 010.
Remount the pickoff headstock
guard.
MOUNTING
What to do ? How ? What for ? Notes
To mount:
Replace Bushing 020: for details see overleaf
Fit Notched Disk 010: for details see overleaf
Fit Locking Mechanism: for details see overleaf
Angular adjustment: for details see Page 17.1/5
To Next Page
