CHANGING POLYGONING CUTTER
To start with : Put the machine in SETTING mode.
What to do ? Notes
Dismounting
Unscrew Fastening Screw 180 ...
Dismount the cutter.
... while holding the cutter to
avoid rotation.
Mounting
Fit the cutter and fix it with Screw 180. ... while holding the cutter to
avoid rotation.
GREASING BEVEL GEARS
Maintenance Interval: Grease bevel gears annually or at least every
3000 hours’ operation.
What to do ? Notes
Dismounting
Undo and remove three Screws 420.
Pull out Drive Shaft Unit 030.
...Do not lose Rings 040.
Greasing
Proceed to grease the pair of bevel
gears.
See Instruction 300231, Para
2.2.2 : MANUAL GREASING OF
PINION OR BEVEL GEARS
Mounting
Fit in Drive Shaft Unit 030.
Screw in and tighten three Screws
420.
