TestProcedure(continued)
A.Thereshouldbenoshakingorvibrationinthesteeringwheelorrear
wheels.
B.Thesteeringwheelmovementsshouldbefollowedimmediatelyby
acorrespondingrearwheelmovementwithoutthesteeringwheel
continuingtoturn.
3.Stopunitwiththeenginerunning.Turnthesteeringwheelwithsmallquick
movementsinbothdirections.Letgoofthesteeringwheelaftereach
movement.
A.Thesteeringcontrolvalveshouldrespondtoeachsteeringwheel
movement.
B.Whensteeringwheelisreleased,steeringcontrolshouldreturntothe
neutralpositionwithnoadditionalturning.
4.Ifeitheroftheseperformancetestsindicateasteeringproblem,determineif
thesteeringcylinderisdamagedusingthefollowingprocedure:
A.ParkthemachineonalevelsurfacewiththePTOswitchoff,lowerthe
cuttingdeck,andsettheparkingbrake.
B.Withtheenginerunning,turnthesteeringwheeltotheright(clockwise)
untilthesteeringcylinderrodisfullyextendedandshutofftheengine.
C.ReadallWarning,Cautions,andprecautionslistedatthebeginningof
thissection.
D.Cleanthettingandhoseend,disconnectthehydraulichosefromthe
ttingontherodendofthesteeringcylinder.
E.Useanelboworateettingwithaholepluggedandinstallapressure
gaugeattheendofthedisconnectedhose.
F.Withtheengineshutoff,continueturningthesteeringwheeltotheright
(clockwise)withthesteeringcylinderfullyextended.Monitortheopen
ttingonthesteeringcylinderasthewheelisturned.Ifthehydraulicuid
comesoutofthettingwhileturningthesteeringwheeltotheleft,the
steeringcylinderhasinternalleakageandshouldberepairedorreplaced.
5.Thesteeringcircuitreliefvalvelocatedinthesteeringcontrolvalvecanbe
testedwiththepressuregaugeinstalledinthesamelocationasthesteering
cylindertest(step4)asfollows:
A.Starttheengineandrunitatlow-idlespeed.Checkforhydraulic-uid
leaksfromthetestconnectionsandcorrectbeforecontinuingthetest.
B.Settheenginespeedtoapproximately2,000rpm.Useatachometerto
checkthattheenginespeediscorrect.
IMPORTANT
Holdthesteeringwheelatfulllockonlylongenoughtogeta
systempressurereading.Holdingthesteeringwheelagainstthe
stopforanextendedperiodmaydamagethesteeringcontrol
valve.
C.Monitorthepressuregaugecarefullywhenturningthesteeringwheelfor
arighthandturn(clockwise)andholding.
D.Thesystempressureshouldbeapproximately7,240kPa(1,050psi)as
thereliefvalvelifts.
E.ReturnthesteeringwheeltotheNEUTRALposition,shutofftheengine,
andrecordthetestresults.
Groundsmaster
®
3280-D/3320
Page5–67
HydraulicSystem:TestingtheHydraulicSystem
05138SLRevB
