RemovingtheSteeringCylinder(2-WheelDrive)

1.Parkthemachineonalevelsurface,lowercuttingdeck(orimplement),shut

offtheengine,settheparkingbrake,andremovethekeyfromthekeyswitch.

2.ReadtheGeneralPrecautionsforRemovingandInstallingtheHydraulic

SystemComponents(page5–77).

CAUTION

Beforeopeningthehydraulicsystem,operateallthehydraulic

controlstoreleasesystempressureandavoidinjuryfromthe

pressurizedhydraulicuid;refertoReleasingPressurefromthe

HydraulicSystem(page5–6).

3.Forassemblypurposes,labelallthehydraulichosesthatareconnectedto

thettingsonthesteeringcylinder.

4.Cleanthehydraulichoseendsbeforeyoudisconnectthehosesfromthe

steeringcylinder.

5.Disconnectthehydraulichosesfromthesteeringcylinder.

6.Installcapsorplugsonthedisconnectedhosesandttingstoprevent

contamination.

7.Removethebolts(items1and8inFigure97)and2locknutsthatsecure

thesteeringcylindertothemachine.

g225168

Figure98

1.Bolt5.Bolt

2.Flangenut(2each)6.Steeringcylinder

3.Cylinderspacer7.Steeringpivotplate

4.Spacerring

8.Thrustwasher

8.Pullthesteeringcylinderfromthemachine.Locateandretrievethespacer

ringandthrustwasher,andnotethelocationforinstallationpurposes(Figure

98).

9.Ifthehydraulicttingsaretoberemovedfromthesteeringcylinder,mark

thettingorientationforassemblypurposes.Removethettingsfromthe

steeringcylinderanddiscardtheO-ringsfromthettings.

HydraulicSystem:ServiceandRepairs

Page5–118

Groundsmaster

3280-D/3320
