AccessoryPowerSwitch(MachineswithOperatorCab)
g243784
Figure140
1.Switchpanel
2.Accessorypowerswitch
Theaccessorypowerswitchcontrolsthepowersupplytotheaccessorypower
outlet.Theswitchislocatedinthecabheadliner(Figure140).
TestingtheAccessoryPowerSwitch
1.Parkthemachineonalevelsurface,lowerthecuttingdeck,settheparking
brake,andshutofftheengine.
2.Toaccesstheaccessorypowerswitch,removetherooffromthetopofthe
cab;refertoRoofAssembly(page11–3).
3.Removetheswitchpanelfromthecabheadliner.
4.Disconnectthewireharnesselectricalconnectorfromtheaccessorypower
switch.
g243573
Figure141
BackofSwitch
5.TheaccessorypowerswitchterminalsareidentiedinFigure141andthe
circuitryoftheswitchisshownintheCircuitLogicT able(page6–41).With
theuseofamultimeter(ohmssetting),testtheswitchfunctionstodetermine
ifcontinuityexistsbetweenthevariousterminalsforeachswitchposition.
Checkthecontinuitybetweentheswitchterminals.
ElectricalSystem:TestingtheElectricalComponents
Page6–40
Groundsmaster
®
3280-D/3320
05138SLRevB
