Installing
the
Lift
Control
V
alve
Solenoid
V
alve
Coils
1.
Slide
the
coil
assembly
onto
the
hydraulic
valve.
2.
Install
the
nut
onto
the
valve
and
torque
the
nut
to
6.7
N∙m
(5
in-lb)
.
Note:
Do
not
overtighten
the
nut.
3.
Connect
the
machine
wire
harness
connector
to
the
solenoid
coil.
