Figure189
1.Pneumaticsuspension
assembly
2.Flange-headscrew(4
each)
3.Lowerseatbracket(2
each)
RemovingthePneumaticSeatSuspension
1.Parkthemachineonalevelsurface,lowerthecuttingdeck(orimplement),
shutofftheengine,settheparkingbrake,andremovethekeyfromthe
keyswitch.
IMPORTANT
Donotdamagetheelectricalharnesswhenremovingtheseat
suspensionfromthemachine.
2.Removetheseatandseatsuspensionfromthemachine;refertoOperator
Seat(page7–19).
3.Removethepneumaticseatsuspensioncomponentsasnecessary(Figure
188andFigure189).
InstallingthePneumaticSeatSuspension
1.Installthepneumaticseatsuspensioncomponents(Figure188andFigure
189).RefertoFigure188forfastenertorquevaluesforassemblypurposes.
IMPORTANT
Donotdamagetheelectricalharnesswheninstallingtheseat
suspensiontothemachine.
2.Installtheseatandseatsuspensiontothemachine;refertoOperatorSeat
(page7–19).Ensuretoconnecttheharnesselectricalconnectortothe
seatswitch.
Groundsmaster
®
3280-D/3320
Page7–25
Chassis:ServiceandRepairs
05138SLRevB
