RemovingtheLiftArms

g224019

Figure191

1.Liftarm(left)4.Rivet(3each)7.Plainwasher(3each)

2.Flangebushing(2each)

5.Plasticpad

8.Sphericalbearing

3.Greasetting(2each)

6.Rubberpad9.Retainingring

g224020

Figure192

1.Innerrollpinsplit

3.Rollpinendsushwithpivotpinsurface

2.outerrollpinsplit

1.Parkthemachineonalevelsurface,lowerthecuttingdeck(orimplement),

shutofftheengine,settheparkingbrake,andremovethekeyfromthe

keyswitch.

2.Removethecuttingdeckfromtheliftarm;refertotheCuttingUnitOperator’s

Manual.

3.Disconnectthebrakereturnspringfromtheliftarm.

4.Removetheliftarmcomponentsfromthemachine(Figure190).

5.Ifnecessary,disassembletheliftarm(Figure191).

Groundsmaster

3280-D/3320

Page7–27

Chassis:ServiceandRepairs

05138SLRevB
