AssemblingtheFrontAxle(continued)

g225935

Figure246

22.Useadialindicator,checktheringgearbacklashin3equallyspacedpoints.

Theringgearbacklashshouldbe0.076to0.178mm(0.003to0.007inch)

andmustnotvarymorethan0.05mm(0.002inch)betweenthepoints

checked(Figure246).

Ifthebacklashisnotinthisrange,movetheshimswhicharelocatedbelow

thedifferentialbearings,fromonesidetotheotheruntilthecorrectbacklash

isattained.

23.Checktheringtopiniongearengagement;refertoRingtoPinionGear

Engagement(FrontAxle)(page8–40).

g225936

Figure247

24.Applysiliconesealantbetweenthefrontandtherearaxlehousingsand

installthe8housingbolts.T orquetheboltsto24to31N·m(18to23ft-lb)

(Figure247).

25.Installtherightandleft-handaxleassemblies;refertoFrontAxleShaftsand

Bearings(page8–8).

Groundsmaster

3280-D/3320

Page8–39

DriveAxles:ServiceandRepairs

05138SLRevB
