InspectingtheBevelGearCaseandAxleCase

g226462

Figure260

1.Knucklepin2.Axlecasesupport

1.Measuretheknucklepinouterdiameterandtheaxlecasesupportbushing

innerdiametertodeterminethebushingtopinclearance(Figure260).

Replacethecomponentsasnecessary.

Bushingtopinclearance:0.05to0.40mm(0.002to0.016inch)

Knucklepinouterdiameter(factoryspecication):24.95to24.98mm(0.982

to0.983inch)

Axlecasesupportbushinginnerdiameter(factoryspecication):25.00to

25.08mm(0.984to0.987inch)

2.Inspectallgears,shafts,bearings,cases,andcoversfordamageandwear.

Replacethecomponentsasnecessary.

InstallingtheBevelGearCaseandAxleCase(4-WheelDriveAxle)

g226463

Figure261

1.Axlecase2.Bevelgearcase

3.Shaftseal

1.Coatnewshaftsealswithgreaseandinstalltheshaftsealsintheaxlecase

andbevelgearcase(Figure261).

DriveAxles:ServiceandRepairs

Page8–52

Groundsmaster

3280-D/3320

05138SLRevB
