InstallingtheAxleShaft(4-WheelDriveAxle)

g226488

Figure270

1.Axlecover

3.Axleshaft

2.Bearing

4.Axleshaftseal

1.Coatnewaxleshaftsealwithgreaseandinstalltheshaftsealintheaxle

cover(Figure270).

2.Presstheaxlecoverandbearingassemblyontotheaxleshaft.Pressonly

ontheinnerraceofthecoverbearing(Figure270).

3.Installtheretainingring,spacer,andcorrectcombinationofbearingshims.

Installthebevelgearandbearing.

4.CoatanewO-ringwithgreaseandinstalltheaxlecoverassembly.Tighten

theaxlecoverscrewsto23to27N·m(17to20ft-lb).

DriveAxles:ServiceandRepairs

Page8–60

Groundsmaster

3280-D/3320

05138SLRevB
