RemovingtheGearbox(continued)
g223658
Figure305
1.Oilcap
4.Washer
7.Oilcap
2.Oilseal(2each)5.90°elbowtting8.Gearbox
3.Breatherplug6.Plug9.Dipstick
CuttingUnits:ServiceandRepairs
Page10–16
Groundsmaster
®
3280-D/3320
05138SLRevB
