AirCleaner

RemovingtheAirCleaner

1.Removeaircleanercomponentsasnecessary(Figure13).

2.RefertotheTractionUnitOperator’sManualforaircleanerservice

procedures.

g230319

Figure13

1.Aircleanerassembly5.Hoseclamp9.Airinlethose

2.Flatwasher(2each)6.Bolt(2each)10.Bolt(2each)

3.Locknut

7.Lockwasher(2each)

11.Mountingbracket

4.Airinlethose

8.Spacer

InstallingtheAirCleaner

IMPORTANT

Anyleaksintheairltersystemwillallowunlteredairtoenter

engineandwillcauseseriousenginedamage.Ensurethattheallair

cleanercomponentsareingoodconditionandareproperlysecured

duringassembly.

1.Assembleaircleanersystem(Figure13).Ensurethatthevacuatorvalveis

pointeddownafterassembly.

GasolineEngine:ServiceandRepairs

Page3–12

Groundsmaster

3280-D/3320

05138SLRevB
