ExhaustSystem
g222270
Figure24
1.Gasket4.Exhaustmufer7.Bolt(2each)
2.Upperalternatorbrace
5.Flangenut(2each)8.Mufermount
3.Flangenut(4each)6.Hardenedwasher(4each)
9.Engine
RemovingtheExhaustSystem
CAUTION
Ahotengineandexhaustsystemcancauseburns.
Allowtheengineandtheexhaustsystemtocoolbeforeworking
onornearthem.
1.Parkthemachineonalevelsurface,lowerthecuttingdeck(orimplement),
shutofftheengine,settheparkingbrake,andremovethekeyfromthe
keyswitch.
2.Unlatchthehoodandraiseit.
Groundsmaster
®
3280-D/3320
Page4–9
DieselEngine:ServiceandRepairs
05138SLRevB
